Repository CR

Repository CR #

The Repository CR serves the following purposes:

  • Informing Pipelines-as-Code that an event from a specific URL needs to be handled.
  • Specifying the namespace where the PipelineRuns will be executed.
  • Referencing an API secret, username, or API URL if necessary for Git provider platforms that require it (e.g., when using webhooks instead of the GitHub application).
  • Providing the last PipelineRunstatuses for the repository (5 by default).
  • Let you declare custom parameters within the PipelineRunthat can be expanded based on certain filters.

The process involves creating a Repository CR inside the target namespace my-pipeline-ci, using the tkn pac CLI or another method.

For example, this will create a Repo CR for the github repository https://github.com/linda/project

cat <<EOF|kubectl create -n my-pipeline-ci -f-
apiVersion: "pipelinesascode.tekton.dev/v1alpha1"
kind: Repository
metadata:
  name: project-repository
spec:
  url: "https://github.com/linda/project"
EOF

With this configuration when an event from the linda/project repository occurs, Pipelines-as-Code will know it needs to be handled and begin checking out the contents of linda/project to match with the PipelineRun in the .tekton/ directory.

If the PipelineRun matches via its annotations the event, for example on a specific branch and event like a push or pull_request. It will start the PipelineRun where the Repository CR has been created. You can only start the PipelineRun in the namespace where the Repository CR is located.

Setting PipelineRun definition source #

An additional layer of security can be added by using a PipelineRun annotation to explicitly target a specific namespace. However, a Repository CRD must still be created in that namespace for it to be matched.

This annotation helps prevent bad actors on a cluster from hijacking PipelineRun execution to a namespace they don’t have access to. It let the user specify the ownership of a repo matching the access of a specific namespace on a cluster

To use this feature, add the following annotation to the pipeline:

pipelinesascode.tekton.dev/target-namespace: "mynamespace"

Pipelines-as-Code will then only match the repository in the mynamespace namespace instead of trying to match it from all available repositories on the cluster.

Pipelines-as-Code installs a Kubernetes Mutating Admission Webhook to ensure that only one Repository CRD is created per URL on a cluster.

If you disable this webhook, multiple Repository CRDs can be created for the same URL. However, only the oldest created Repository CRD will be matched, unless you use the target-namespace annotation.

PipelineRun definition provenance #

By default on a Push or a Pull Request, Pipelines-as-Code will fetch the PipelineRun definition from the branch of where the event has been triggered.

This behavior can be changed by setting the setting pipelinerun_provenance. The setting currently accept two values:

  • source: The default behavior, the PipelineRun definition will be fetched from the branch of where the event has been triggered.
  • default_branch: The PipelineRun definition will be fetched from the default branch of the repository as configured on the git platform. For example main, master, or trunk.

Example:

This configuration specifies a repository named my-repo with a URL of https://github.com/my-org/my-repo. It also sets the pipelinerun_provenance setting to default_branch, which means that the PipelineRun definition will be fetched from the default branch of the repository.

apiVersion: "pipelinesascode.tekton.dev/v1alpha1"
kind: Repository
metadata:
  name: my-repo
spec:
  url: "https://github.com/owner/repo"
  settings:
    pipelinerun_provenance: "default_branch"
Letting the user specify the provenance of the PipelineRun definition to default branch is another layer of security. It ensures that only the one who has the right to merge commit to the default branch can change the PipelineRun and have access to the infrastrucutre.

Concurrency #

concurrency_limit allows you to define the maximum number of PipelineRuns running at any time for a Repository.

spec:
  concurrency_limit: <number>

If there is multiple PipelineRuns matching the event, the PipelineRuns that match the event will always be started in alphabetical order.

Example:

If you have three pipelineruns in a .tekton directory, and you create a pull request with a concurrency_limit of 1 in the repository configuration, then all of the pipelineruns will be executed in alphabetical order, one after the other. At any given time, only one pipeline run will be in the running state, while the rest will be queued.

Scoping GitHub token to a list of private and public repositories within and outside namespaces #

By default, the GitHub token that Pipelines-as-Code generates is scoped only to the repository where the payload comes from. However, in some cases, the developer team might want the token to allow control over additional repositories. For example, there might be a CI repository where the .tekton/pr.yaml file and source payload might be located, however the build process defined in pr.yaml might fetch tasks from a separate private CD repository.

You can extend the scope of the GitHub token in two ways:

  • Global configuration: extend the GitHub token to a list of repositories in different namespaces and admin have access to set this configuration.

  • Repository level configuration: extend the GitHub token to a list of repositories that exist in the same namespace as the original repository and both admin, non-admin have access to set this configuration.

when using a GitHub webhook, the scoping of the token is what you set when creating your fine grained personal access token.

Prerequisite

  • In the pipelines-as-code configmap, set the secret-github-app-token-scoped key to false. This setting enables the scoping of the GitHub token to private and public repositories listed under the Global and Repository level configuration.

Scoping the GitHub token using Global configuration #

You can use the global configuration to use as a list of repositories used from any Repository CR in any namespaces.

To set the global configuration, in the pipelines-as-code configmap, set the secret-github-app-scope-extra-repos key, as in the following example:

apiVersion: v1
kind: ConfigMap
metadata:
  name: pipelines-as-code
  namespace: pipelines-as-code
data:
  secret-github-app-scope-extra-repos: "owner2/project2, owner3/project3"

Scoping the GitHub token using Repository level configuration #

You can use the Repository custom resource to scope the generated GitHub token to a list of repositories. The repositories can be public or private, but must reside in the same namespace as the repository with which the Repository resource is associated.

Set the github_app_token_scope_repos spec configuration within the Repository custom resource, as in the following example:

apiVersion: "pipelinesascode.tekton.dev/v1alpha1"
kind: Repository
metadata:
  name: test
  namespace: test-repo
spec:
  url: "https://github.com/linda/project"
  settings:
    github_app_token_scope_repos:
    - "owner/project"
    - "owner1/project1"

In this example, the Repository custom resource is associated with the linda/project repository in the test-repo namespace. The scope of the generated GitHub token is extended to the owner/project and owner1/project1 repositories, as well as the linda/project repository. These repositories must exist under the test-repo namespace.

Note:

If any of the repositories does not exist in the namespace, the scoping of the GitHub token fails with an error message as in the following example:

failed to scope GitHub token as repo owner1/project1 does not exist in namespace test-repo

Combining global and repository level configuration #

  • When you provide both a secret-github-app-scope-extra-repos key in the pipelines-as-code configmap and a github_app_token_scope_repos spec configuration in the Repository custom resource, the token is scoped to all the repositories from both configurations, as in the following example:

    • pipelines-as-code configmap:

      apiVersion: v1
      kind: ConfigMap
      metadata:
        name: pipelines-as-code
        namespace: pipelines-as-code
      data:
        secret-github-app-scope-extra-repos: "owner2/project2, owner3/project3"

    • Repository custom resource

       apiVersion: "pipelinesascode.tekton.dev/v1alpha1"
       kind: Repository
       metadata:
         name: test
         namespace: test-repo
       spec:
         url: "https://github.com/linda/project"
         settings:
           github_app_token_scope_repos:
           - "owner/project"
           - "owner1/project1"


      The GitHub token is scoped to the following repositories: owner/project, owner1/project1, owner2/project2, owner3/project3, linda/project.

  • If you set only the global configuration in the secret-github-app-scope-extra-repos key in the pipelines-as-code configmap, the GitHub token is scoped to all the listed repositories, as well as the original repository from which the payload files come.

  • If you set only the github_app_token_scope_repos spec in the Repository custom resource, the GitHub token is scoped to all the listed repositories, as well as the original repository from which the payload files come. All the repositories must exist in the same namespace where the Repository custom resource is created.

  • If you did not install the GitHub app for any repositories that you list in the global or repository level configuration, creation of the GitHub token fails with the following error message:

    failed to scope token to repositories in namespace test-repo with error : could not refresh installation id 36523992's token: received non 2xx response status \"422 Unprocessable Entity\" when fetching https://api.github.com/app/installations/36523992/access_tokens: Post \"https://api.github.com/repos/savitaashture/article/check-runs\

  • If the scoping of the GitHub token to the repositories set in global or repository level configuration fails for any reason, the CI process does not run. This includes cases where the same repository is listed in the global or repository level configuration, and the scoping fails for the repository level configuration because the repository is not in the same namespace as the Repository custom resource.

    In the following example, the owner5/project5 repository is listed in both the global configuration and in the repository level configuration:

    apiVersion: v1
    kind: ConfigMap
    metadata:
      name: pipelines-as-code
      namespace: pipelines-as-code
    data:
      secret-github-app-scope-extra-repos: "owner5/project5"

    apiVersion: "pipelinesascode.tekton.dev/v1alpha1"
    kind: Repository
    metadata:
      name: test
      namespace: test-repo
    spec:
      url: "https://github.com/linda/project"
      settings:
        github_app_token_scope_repos:
        - "owner5/project5"


    In this example, if the owner5/project5 repository is not under the test-repo namespace, scoping of the GitHub token fails with the following error message:

    failed to scope github token as repo owner5/project5 does not exist in namespace test-repo
